| Code | Bolt Description | Diameter | Length | Surface Finish | Weight | Packing QTY/Pallet | Ring ColorID | |||||
| (mm) | (mm) | (Kgs) | ||||||||||
| FB47-0900 | Split Set Bolt 47-900 | 47 | 900 | Untreated | 2.50 | 150 | - | |||||
| FB47-1800 | Split Set Bolt 47-1800 | 47 | 1800 | Untreated | 5.10 | 150 | - | |||||
| FB47-2100 | Split Set Bolt 47-2100 | 47 | 2100 | Untreated | 6.10 | 150 | - | |||||
| FB47-2400 | Split Set Bolt 47-2400 | 47 | 2400 | Untreated | 6.70 | 150 | - | |||||
| FB47-3000 | Split Set Bolt 47-3000 | 47 | 3000 | Untreated | 8.60 | 150 | - | |||||
| FB47-0900G | Split Set Bolt 47-900 HDG | 47 | 900 | Hot Dip Galvanized | 2.60 | 150 | - | |||||
| FB47-1800G | Split Set Bolt 47-1800 HDG | 47 | 1800 | Hot Dip Galvanized | 5.50 | 150 | Red | |||||
| FB47-2100G | Split Set Bolt 47-2100 HDG | 47 | 2100 | Hot Dip Galvanized | 6.40 | 150 | Green | |||||
| FB47-2400G | Split Set Bolt 47-2400 HDG | 47 | 2400 | Hot Dip Galvanized | 7.05 | 150 | - | |||||
| FB47-3000G | Split Set Bolt 47-3000 HDG | 47 | 3000 | Hot Dip Galvanized | 9.00 | 150 | Yellow | |||||
